CNC Machined X-Ray Equipment Components

Custom Machined Components for X-Ray Equipment
X-ray imaging equipment requires accurately manufactured mechanical components for mounting, positioning, adjustment, and assembly. FlexiTurn provides custom CNC machined X-ray equipment components based on customer drawings and CAD files, including collimator components, detector mounts, positioning brackets, support structures, equipment housings, and precision mounting interfaces.

With 3-axis, 4-axis, and 5-axis CNC machining capabilities, we manufacture complex components with multiple surfaces, holes, slots, and functional features required for different equipment designs. From prototypes and small batches to repeat production, each part is manufactured according to customer specifications and inspection requirements.

Components Built Around Your X-Ray Equipment Design
X-ray systems contain various mechanical structures and interfaces depending on equipment configuration. FlexiTurn specializes in OEM and non-standard CNC machining for customized components.

Typical machined components include:

Collimator Components:
Machined frames, plates, guides, mounting parts, and adjustment components used in beam-limiting assemblies.

Detector Mounts and Supports:
Rigid mounting structures with accurately positioned holes and interfaces for detector assemblies.

Positioning and Alignment Components:
Brackets, fixtures, supports, and mechanical interfaces used for equipment positioning.

Tube and Equipment Mounting Parts:
Custom-machined components designed around specific equipment structures and installation requirements.

Diagnostic Equipment Housings:
CNC-machined covers and housings for mechanical or electronic assemblies.

General Precision Components:
Plates, blocks, brackets, fixtures, and other machined mechanical parts used in X-ray equipment.

CNC Machining for Complex Imaging Components
Different X-ray components require different machining approaches. Some parts involve complex contours and angled surfaces, while others require precise holes, bores, slots, and threaded features.

FlexiTurn combines CNC milling, CNC turning, drilling, tapping, and multi-axis machining to manufacture components according to their geometry and application requirements. 5-axis machining helps reduce setups for complex parts and improves consistency between multiple features.

Materials and Surface Finishing
FlexiTurn machines commonly used materials for X-ray equipment components, including aluminum, stainless steel, steel alloys, and engineering plastics.

Aluminum is widely selected for lightweight housings, brackets, mounting parts, and structural components, while stainless steel and steel alloys are used when higher strength or durability is required.

We also provide surface finishing services including anodizing, sandblasting, powder coating, and laser engraving according to material requirements and customer specifications.

From Design Review to Finished Components
FlexiTurn supports manufacturing based on 2D drawings, 3D CAD files, and samples. Our engineering team can provide DFM support before production to identify machining considerations and improve manufacturability.

The manufacturing process can include design review, CNC machining, surface treatment, CMM inspection, and final verification, providing customers with a complete manufacturing workflow from initial design to finished components.

Quality Control for X-Ray Components
X-ray equipment components often require accurate fitting with other mechanical assemblies. FlexiTurn follows customer drawing requirements and performs in-process inspection and final dimensional verification.

For components requiring detailed measurement or critical alignment features, CMM inspection and dimensional inspection reports are available to ensure consistent quality.

OEM and Non-Standard CNC Manufacturing
FlexiTurn focuses on custom manufacturing rather than standardized replacement parts. Whether you need prototype components for new equipment development, small-batch production, or repeat manufacturing, we can produce parts based on your technical requirements.

Manufacturing Capabilities
Materials: Aluminum, Stainless Steel, Steel Alloys, Engineering Plastics

Machining: 3-Axis, 4-Axis, 5-Axis CNC Milling, CNC Turning, Drilling, Tapping

Surface Treatment: Anodizing, Sandblasting, Powder Coating, Laser Engraving

Drawing Formats: 2D / PDF, 3D / IGES, STEP

Tolerance: According to Customer Drawing Requirements

Quality Control: In-Process Inspection, Final Dimensional Verification, CMM Inspection

Production: Prototypes, Small Batches, Production Parts

Customization: OEM, Non-Standard, Drawing-Based Manufacturing
